The Whale Easi-Slide Body - Water Inlet With Pressure Switch provides a convenient external fresh water connection for caravans, motorhomes and campervans using a compatible Whale water supply system.
Designed as part of the Whale Easi-Slide utility point range, this version incorporates an integrated pressure switch, allowing the pump to respond to changes in pressure within the vehicle's water system. When a tap or shower is opened and the pressure drops, the pressure switch activates the connected pump to supply water.
The inlet can be used with compatible Whale Watermaster external submersible pumps and is also suitable for connection to the Whale Watermaster mains water system. Whale specifically lists the Watermaster EP1612 and Watermaster Mains EM9433 as suitable products for this inlet.
A 12mm male Whale Quick Connect stem on the rear provides a straightforward connection into compatible Whale 12mm plumbing systems. The unit operates from a 12V DC electrical supply and the external face is rated IP45 when the Easi-Slide lid is closed.
As with the other modular Whale Easi-Slide products, the utility point body and exterior lid are purchased separately. This allows you to select the Easi-Slide lid colour and style to match the other external utility points fitted to your vehicle.
The SO4000C is designed for use with the Whale Easi-Slide Water Icon Lid, available separately in:
Choose the lid colour to match the exterior finish of your caravan, motorhome or campervan.
IMPORTANT: This listing is for the Whale Easi-Slide water inlet body only. An Easi-Slide lid is NOT included and must be purchased separately.
No. This listing is for the Whale Easi-Slide utility point body only. A compatible Whale Easi-Slide lid must be purchased separately.
The pressure switch detects changes in water pressure within the system. When a tap or shower is opened and the system pressure drops, it can switch the connected pump on to provide water.
Yes. ES6001 is Whale's Easi-Slide water inlet with an integrated pressure switch. Whale also produces other Easi-Slide water inlet versions for different water system configurations, so it is important to select the correct model.
The rear of the inlet has a 12mm male stem designed for connection to compatible Whale Quick Connect plumbing.
Yes. Whale specifies the Water In Easi-Slide range as 12V DC.
Yes. Whale identifies the Watermaster EP1612 exterior water pump with Easi-Push plug as suitable for this Easi-Slide water inlet.
Yes. Whale also identifies its Watermaster Mains EM9433 as suitable for use with the Water In Easi-Slide socket.
The inlet itself is designed for cold fresh water only. It supplies the vehicle's fresh water system, which can subsequently supply taps, showers and the vehicle's water heater.
