The Whale Easi-Slide Onboard Tank Fill Socket with 12V is a clever 2-in-1 external filling point, combining a fresh water tank filler with a 12V DC power connection in one neat unit for motorhomes, caravans and campervans.
Designed to be installed into the exterior wall of the vehicle, the socket allows an onboard fresh water tank to be filled using a standard water hose. The integrated 12V connection can also provide power for a compatible external water pump, making it particularly useful with the Whale Superfil Pump Kit when water needs to be pumped from an external container into the onboard tank.
A built-in secure hose clip helps keep the filling hose in position during use, reducing the need to continuously hold the hose while the tank is filling.
At the rear, the socket features a 40mm connection for the main water filler hose together with a separate 10mm bleed/breather connection. Correct connection of the breather allows displaced air to escape as the tank fills, helping prevent airlocks and providing smoother, more reliable filling.
Part of Whale's Easi-Slide exterior socket range, the SO2500C is designed for use with the compatible locking Easi-Slide Water Icon lid, available separately in a choice of colours.
The Whale SO2500C is designed specifically for cold fresh water systems and provides an excellent solution for new campervan and motorhome conversions or replacement of an existing compatible Whale installation.
The SO2500C is designed for use with the Whale Easi-Slide Water Icon Lid WITH LOCK, available separately in:
This allows you to select a lid colour to complement the exterior of your caravan, motorhome or campervan.
The Easi-Slide lid, lock and keys are NOT included with the SO2500C socket and must be purchased separately.
This listing is for the Whale SO2500C Onboard Tank Fill + 12V Socket only, unless otherwise specifically stated.
The SO2500C provides an external filling point for an onboard fresh water tank while also incorporating a 12V DC electrical connection for powering a compatible external water pump.
It allows a compatible 12V external pump to receive power directly from the socket. This is particularly useful when transferring fresh water from an external container into the vehicle's onboard water tank.
Yes. Whale specifically identifies the Superfil Pump Kit as an ideal companion for the SO2500C, providing a convenient way to pump water into the onboard tank.
Yes. The socket is suitable for use with a standard water hose, so you don't have to use an electric pump when a suitable pressurised water supply is available.
The main rear plumbing connection is designed for a 40mm diameter filler hose.
The separate bleed/breather connection is designed for a 10mm diameter hose.
As water enters the tank, displaced air needs to escape. Correctly connecting the 10mm breather helps reduce airlocks, blowback and interrupted filling.
No. The locking Easi-Slide Water Icon lid is sold separately, allowing you to choose the required colour.
The SO2000C provides an external filling point for the onboard water tank. The SO2500C adds a 12V DC power connection, creating a 2-in-1 filler and pump power socket.
