Scanstrut TILE USB-A & USB-C Charger 12V 24V 60W Low Profile

Scanstrut TILE USB-A & USB-C Charger – Low Profile Campervan Charging

Upgrade your campervan interior with the Scanstrut TILE Series USB-A & USB-C Charger, a sleek and compact charging solution designed for modern van conversions.

With its ultra-low profile and minimal footprint, this charger integrates neatly into your panels while delivering powerful, high-speed charging for everyday devices.

Designed to complement premium campervan interiors, the TILE Series offers a clean, modern finish without compromising on performance.

Key Features & Benefits

• USB-A & USB-C ports – Charge a wide range of devices simultaneously
• Fast charging performance – Up to 60W output on 24V systems
• 12V & 24V compatible – Suitable for most campervan electrical systems
• Ultra-low profile design – Clean, low-profile finish
• Compact footprint – Requires only a 29mm hole for installation
• Front-fit installation – Simple and efficient fitting
• Moisture-protected electronics – Conformal coated for added durability
• Premium finish options – Available in 316 stainless steel or matt black
• Modern interior styling – Designed for high-end campervan builds

Charging Performance

• USB-C Output:
  • 12V System: Up to 36W
  • 24V System: Up to 60W
• USB-A Output:
  • Fast charging supported across 12V and 24V systems
• Suitable for:
  • Smartphones
  • Tablets
  • Laptops (USB-C on 24V systems)
  • USB-powered devices

Note: Full 60W output is available on 24V systems. For best performance, use high-quality charging cables.

Electrical Specifications

• Input Voltage: 10–32V DC (12V / 24V systems)
• Input Current: Max 6A (10A fuse recommended)

USB-C Output (12V System):

• 5V⎓3A
• 9V⎓3A
• 12V⎓3A

USB-C Output (24V System):

• 5V⎓3A
• 9V⎓3A
• 12V⎓3A
• 15V⎓3A
• 20V⎓3A

USB-A Output (12V System):

• 5V⎓3A
• 9V⎓3A
• 12V⎓3A

USB-A Output (24V System):

• 5V⎓3A
• 9V⎓3A
• 12V⎓3A
• 15V⎓3A
• 20V⎓3A
• Standby Draw: 0.01W
• Certifications: CE, FCC, UKCA, C-Tick, ROHS, WEEE

What’s Included

• Scanstrut TILE USB-A & USB-C charger unit

Built for Interior Use

• Designed specifically for campervan interior installations
• Conformal coated electronics for moisture resistance
• Durable, high-quality construction
• Clean, modern aesthetic for premium van interiors

Easy Installation

• Requires 29mm (1.14") holesaw cut-out
• Compact 40mm footprint
• Front-fit design for simple installation
• Low-profile finish for a neat, integrated look

Important:
This product is designed for interior use only. Do not install in areas exposed to water.
